15.6" Legion 5i Gaming Notebook (Phantom Black)
Product Description
Play through your favorite titles with the 15.6" Legion 5i Gaming Notebook from Lenovo. Designed for high-powered performance, this laptop features an 11th Gen Intel Core i7 14-core processor with 16GB of RAM. Store your gaming library and launch applications quickly using the 1TB SSD. A 15.6" Full HD IPS display offers a 165 Hz refresh rate for smooth on-screen action. The NVIDIA GeForce RTX 3060 features 6GB of GDDR6 memory for high frame-rates, powerful visuals, and ray tracing technology. Connect wired accessories via three USB 3.2 Gen 1 Type-A ports and a Thunderbolt 4 port. Pair to wireless peripherals using the integrated Bluetooth technology. Go online with Wi-Fi 6E (802.11ax), providing fast network speeds, necessary for competitive online gaming. Output video to an external monitor using the HDMI 2.1 port or Thunderbolt 4 DisplayPort enabled port. Video conference with family and friends thanks to the 720p webcam and dual-microphone array. A 4-zone RGB keyboard allows for a range of lighting effects to match your gaming aesthetic. The Lenovo 15.6" Legion 5i Series Gaming Laptop runs on the Windows 11 Home (64-Bit) operating system.
| Operating System | Windows 11 Home (64-Bit) |
| Performance | |
| CPU Architecture | x86 |
| Chipset | |
| Processor | Intel Core i7-12700H (12th Gen) |
| CPU Socket | |
| CPU | 2.3 to 4.7 GHz Performance 6-Core 1.7 to 3.5 GHz Efficiency 8-Core |
| L3 Cache | 24 MB |
| Graphics Type | Dedicated |
| GPU | NVIDIA GeForce RTX 3060 (140 W TGP) with 6 GB GDDR6 VRAM |
| Memory Type | 4800 MHz DDR5 |
| Total Installed Memory | 16 GB |
| Memory Configuration | 2 x 8 GB (User-Replaceable) |
| Maximum Memory Capacity | 32 GB |
| Memory Slot Type | 262-Pin SO-DIMM |
| Memory Slots | 2 (0 Available) |
| Buffered Memory | No |
| ECC Memory | No |
| Intel Optane Memory | |
| Afterburner | |
| vPro Support | No |
| Display | |
| Panel Type | IPS-Type LCD |
| Size | 15.6" |
| Aspect Ratio | 16:9 |
| Resolution | 1920 x 1080 |
| Touchscreen | No |
| Finish | Anti-Glare / Matte |
| Maximum Brightness | 300 cd/m2 |
| Color Gamut | 100% sRGB |
| Refresh Rate | 165 Hz |
| Contrast Ratio | |
| Response Time | |
| Variable Refresh Technology | G-Sync |
| Viewing Angle (H x V) | 178 x 178° |
| Storage and Expansion | |
| Total Drive Bays | |
| 2.5" Slots | |
| SSD Slots | 1 x M.2 2242, 2280 PCIe 4.0 x4 (In Use) 1 x M.2 2242, 2280 PCIe 4.0 x4 (Available) |
| Total Installed Capacity | 1 TB |
| Solid State Storage | 1 x 1 TB M.2 NVMe PCIe |
| Hard Disk Storage | |
| Hybrid Storage | |
| MPX Bays | |
| PCI Expansion | |
| PCI Expansion in MPX Bays | |
| Expansion Slots | |
| Optical Drive | None |
| I/O | |
| Ports | 3 x USB-A (USB 3.0 / 3.1/3.2 Gen 1) |
| USB Type-C | 1 x Thunderbolt 4 1 x USB 3.1/3.2 Gen 2 (Supports DisplayPort) 1 x USB 3.1/3.2 Gen 2 (Supports DisplayPort and 135 W Power Delivery) |
| Display | 1 x HDMI 2.1 Output |
| Audio | 1 x 1/8" / 3.5 mm Headphone/Microphone Input/Output |
| Built-In Speakers | 2 x 2 W |
| Built-In Microphones | 2 |
| Media/Memory Card Slot | None |
| Communications | |
| Ethernet | 1 x RJ45 (Gigabit) |
| Wi-Fi | Wi-Fi 6E (802.11ax) |
| MU-MIMO Support | 2 x 2 |
| Bluetooth | 5.1 |
| GPS | None |
| NFC | No |
| Webcam | User-Facing: 720p |
| Battery | |
| Battery Chemistry | Lithium-Ion Polymer (LiPo) |
| Capacity | 4-Cell: 80 Wh |
| Estimated Battery Life | 5 Hours |
| Keyboard & Mouse | |
| Keyboard | Notebook Keyboard with Backlight |
| Pointing Device | TouchPad |
| General | |
| Security | Firmware TPM (Software-Based), Webcam Blocker |
| Power Supply | 300 W with Barrel/Proprietary |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Operating Temperature | |
| Operating Humidity | |
| Certifications | |
| Mounting-Hole Pattern | |
| Dimensions | 14.13 x 10.33 x 0.95" / 358.9 x 262.38 x 24.13 mm |
| Weight | 5.28 lb / 2.39 kg |
