Product Description
Store important files locally using the 256GB PCIe M.2 SSD. Need more space? Connect external drives or other wired accessories via two Thunderbolt 4 ports, which also support DisplayPort and Power Delivery, or two USB 3.2 Gen 1 Type-A ports, one of which supports PowerShare. Or, connect to peripherals with Bluetooth 5.2 and go online using Wi-Fi 6E (802.11ax) or Gigabit Ethernet. Extend or mirror content to additional monitors using the HDMI 2.0 and aforementioned Thunderbolt 4 ports. An integrated microSD card reader also allows for easy access to compatible memory cards. The installed operating system is Windows 10 Pro (64-bit) and included is a 65W USB Type-C power adapter, an E4 power cord, and a Windows 11 Pro (64-bit) license.
| Operating System | Windows 10 Pro (64-Bit) |
| Performance | |
| CPU Architecture | x86 |
| Chipset | |
| Processor | Intel Core i7-1255U (12th Gen) |
| CPU Socket | |
| CPU | 3.5 GHz Efficiency 8-Core 4.7 GHz Performance Dual-Core |
| L3 Cache | 12 MB |
| Graphics Type | Integrated |
| GPU | Intel Iris Xe |
| Memory Type | 3200 MHz DDR4 |
| Total Installed Memory | 16 GB |
| Memory Configuration | 2 x 8 GB (User-Replaceable) |
| Maximum Memory Capacity | 64 GB |
| Memory Slot Type | 260-Pin SO-DIMM |
| Memory Slots | 2 (0 Available) |
| Buffered Memory | No |
| ECC Memory | No |
| Intel Optane Memory | |
| Afterburner | |
| Display | |
| Panel Type | IPS-Type LCD |
| Size | 15.6" |
| Aspect Ratio | 16:9 |
| Resolution | 1920 x 1080 |
| Touchscreen | No |
| Finish | Anti-Glare / Matte |
| Maximum Brightness | 250 cd/m2 |
| Color Gamut | 45% NTSC |
| Refresh Rate | 60 Hz |
| Contrast Ratio | 700:1 |
| Response Time | 35 ms |
| Variable Refresh Technology | |
| Viewing Angle (H x V) | 170 x 170° |
| Storage and Expansion | |
| Total Drive Bays | |
| 2.5" Slots | |
| SSD Slots | 1 x M.2 2280 PCIe 3.0 x4 (In Use) 1 x M.2 2280 PCIe 3.0 x4 (Available) |
| Total Installed Capacity | 256 GB |
| Solid State Storage | 1 x 256 GB M.2 NVMe PCIe |
| Hard Disk Storage | |
| Hybrid Storage | |
| MPX Bays | |
| PCI Expansion | |
| PCI Expansion in MPX Bays | |
| Expansion Slots | 1 x Smart Card |
| Optical Drive | None |
| I/O | |
| Ports | 2 x USB Type-A (USB 3.1 / USB 3.2 Gen 1) |
| USB Type-C | 2 x Thunderbolt 4 (Supports DisplayPort and Power Delivery) |
| Display | 1 x HDMI 2.0 |
| Audio | 1 x 1/8" / 3.5 mm Headphone/Microphone Input/Output |
| Built-In Speakers | 2 x 2 W |
| Built-In Microphones | 2 |
| Media/Memory Card Slot | Single Slot: microSD/microSDHC/microSDXC |
| Communications | |
| Ethernet | 1 x RJ45 (Gigabit) |
| Wi-Fi | Wi-Fi 6E (802.11ax); Tri-Band (2.4, 5, & 6 GHz) |
| MU-MIMO Support | 2 x 2 |
| Bluetooth | 5.2 |
| GPS | None |
| NFC | Yes |
| Webcam | User-Facing: 0.9 MP (1080p) |
| Battery | |
| Battery Chemistry | Lithium-Ion |
| Capacity | 4-Cell: 58 Wh |
| Keyboard & Mouse | |
| Keyboard | Notebook Keyboard with Backlight, Number Pad |
| Pointing Device | TouchPad |
| General | |
| Security | Dedicated Hardware TPM Security Chip, Fingerprint Reader, Wedge-Shaped Lock Slot, Webcam Blocker |
| Power Supply | 65 W with USB Type-C |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 1.7 A |
| Operating Temperature | 32 to 95°F / 0 to 35°C |
| Operating Humidity | 10 to 90% (Non-Condensing) |
| Certifications | ENERGY STAR, EPEATGOLD *as per Manufacturer |
| Mounting-Hole Pattern | |
| Dimensions | 14.09 x 9.19 x 0.87" / 357.89 x 233.43 x 22.1 mm |
| Weight | 3.5 lb / 1.6 kg |
