Product Description
Enjoy high-resolution stereo sound with your music source, speakers, and the Onkyo A-9110 2-Channel 100W Integrated Amplifier. It delivers up to 50W per channel at 4 Ohms and has a phono input and four stereo RCA inputs. The A-9110 features a front-panel 1/4" headphone jack for private listening.
| Amplifier | |
| Number of Channels | 2 |
| Power Rating | 50 W per channel @ 4 Ohms, 20 Hz to 20 kHz, 0.9% THD, 2-channels driven, FTC |
| Speaker Impedance | 4 to 16 Ohms |
| Frequency Response | 10 Hz to 100 kHz, +1, -3 dB (Direct Mode) |
| Signal to Noise Ratio | IHF-A, Line In, Speaker Out: 103 dB IHF-A, Phono In, Speaker Out: 78 dB |
| THD & Noise | 0.05% @ 8 Ohms, 1 kHz, half power |
| Damping Factor | 95 (1 kHz, 8 Ohms) |
| Tone Control | Bass: ±10 dB, 100 Hz Treble: ±10 dB, 10 kHz |
| Connectors | |
| Input | 5 x stereo RCA pairs (1 phono with ground screw) |
| Output | 1 x stereo RCA pair 1 x RCA subwoofer pre-out 1 x 1/4" / 6.35 mm headphone (front) |
| Speaker Connectors | 2 x gold-plated binding post pairs |
| Other Connectors | 1 x 1/8" / 3.5 mm Remote Interactive port |
| Input Sensitivity/Impedance | Line: 200 mV / 47 kOhms Phono MM: 4 mV / 47 kOhms |
| Output Level and Impedance | Line Out: 0.2 V / 2.3 kOhms Phono Overload: 70 mV (MM, 1 kHz, 0.5%) |
| General | |
| Power Requirements | 120 VAC, 60 Hz |
| Power Consumption (Active) | 140 W |
| Power Consumption (Standby) | 0.1 W |
| Dimensions | 17.13 x 5.06 x 13" / 435 x 129 x 330 mm |
| Weight | 15.4 lb / 7 kg |
